1600W For Antminer APW3++ PSU Power Supply Bitmain D3 S9 S7 L3 B3 X3 T9 Original

Name: 1600W For Antminer APW3++ PSU Power Supply Bitmain D3 S9 S7 L3 B3 X3 T9 Original
SKU: 00004
Price: 90.0 USD
Availability: InStock

Home/Store

$90.00

In stock

Product Details

For Bitmain Antminer APW7 PSU 1800W Power Supply Bitcoin Miner Z9 mini S9 V9 T9 S7 L3

Overview:

1. The power cord is not included, please find one with at least 10A from your local market.

2. The APW7 can deliver a maximum power of only 1000W if it is connected to a 110V mains power supply. To obtain the rated power of 1800W, the APW7 must be connected to a 220-240V mains power supply. Please check the mains power supply that is the standard in your region before ordering.

3. This batch of PSU comes with only 10 PCIe connectors so cannot be used with more than one Antminer.

Specifications:

Output	DC Voltage	12.0V
	Rated Current(220V input)	150A
	Rated Power (220V input)	1800W
	Rated Current(110V input)	83.3A
	Rated Power (110V input)	1000W
	Ripple & Noise	<1%
	Voltage Accuracy	12.0-12.5V
	Source Regulation	<1%
	Load Regulation	<1%
	Setup, Rise Time	<2S
	Power off Protection Trip Time	>10mS
Input	Voltage Range	100-264V AC
	Frequency Range	47-63Hz
	Power Factor	>0.99(full load)
	Leakage Current	<1.5mA（220V 50Hz）
Protection	Low-voltage Input	80-89V AC
	Output Short Circuit	Yes
	Output Overcurrent	150-200A
	Overheat Protection	Yes
Environment	Operating Temperature	-20-60℃
	Operating Humidity	20%-90%RH(non-‐condensing)
	Altitude	< 2000m
Structure	Dimensions	20611062mm
Structure	Weight	2.0kg
	Cooling Mode	force-‐air cooling
	Noise	43DB

Package includes:

1 x APW7 PSU (Power cord is not included)
